| Model | A |
|---|---|
| Housing material | aluminium and steel, powdercoating |
| Weight | 2,8 kg |
| Connections | 4 |
| On/off switch with lamp | yes |
| High voltage indication | neonlamp |
| Cable | 1,8 m |
| Ambient temperature | 0 - 50° |
| Use circumstances | industrial |
| Protection classification | IP-54 |
| U primairy | 110 V or 230 V * |
| Frequency | 50 or 60 Hz* |
| Power consumption | 50 Watt |
| U secundairy | 3,3 - 7 kV AC * |
| I secundairy | 2,5 mA max. |
| Option | HR, D |
| Approval | UL |
The standard model has a modern styling featuring easy-access control and connections. It is equipped with an on/off switch with an indicator lamp as well as a high-voltage indicator lamp. This lamp will extinguish if the system is malfunctioning. Four ionizers can be connected as a maximum.
